Infusion Mode

Volume Mode, Time Mode, Drug Mode

Rate Unit

ml/h, volume/time, d/min

IV Sets

Standard single use IV sets ( 10,15,20,60d/mL, with diameter 3.4 ~ 4.5mm)

Flow Rate

1.0ml/h～1200ml/h

1.0d/min～400d/min

Increment

1.0-99.9ml/h in 0.1ml/h step；100-1200ml/ in 1ml/h step

1-400d/min in 1d/min step；

Deviation

Flow Rate：≤5%（after calibration）

VTBI

0.1～9999.9 ml

Total Volume

0.0～9999.9 ml

Time

1min～99h00min

Purge Rate

600ml/h，display purge volume

KVO

1.0ml/h~5.0ml/h，adjustable

Keypad

Numeric keypad,

BOLUS

Bolus function available, flow rate adjustable

Night Mode

Screen to be dim automatically in 5mins after standby time expired.

Occlusion pressure detector

Downstream pressure detection,  40KPa～130KPa, 10 levels adjustable with dynamic pressure value display

Air Bubble Detector

Ultrasonic detection, ≥50ul，Single bubble volume: 50～300 μl, 10 levels adjustable.

Volume

10 levels adjustable

Motor Anti-reverse Function

Anti-reverse function to prevent upstream

IV Set Management

Open system, accept different IV brands after calibration

Self-Testing

Self-Testing before startup and during infusion

Audio Visual Alarm Message

Air bubble, downstream occlusion, door open, infusion finish, standby time expired, battery low, battery empty, battery disengaged, AC Power disengaged, motor error, pump error, pressure sensor error, parameter error, system error

Screen

3.2inch brightness LCD

Power Supply

AC Power：100V～240V，50Hz/60Hz，≤25VA

Battery

Rechargeable Lithium battery, DC11.1V，3000mAh；operating time: ≥10h @25ml/h, displaying remaining battery

Operation Condition

Temperature:+5℃～＋40℃, Humidity：20%～90%，Air pressure：70~106KPa

Transport & Storage

Temperature :-20℃～＋55℃,Humidity：10%~95%，Air pressure：50~106KPa

Classification

Type CF, Class I, IPX3

Dimension

145mm×150mm×200mm；Weight：1.7kg
