Injection Mode

Constant rate, time/volume mode, drug weight mode, micro-mode, programmable mode, drug library mode

Syringe Size

5ml、10ml、20ml、30ml、50/60ml，auto-recognition

Flow Rate

5ml：0.10ml/h-60.00ml/h          10ml：0.10ml/h-300.00ml/h

20ml：0.10ml/h-400.00ml/h        30ml：0.10ml/h-600.00ml/h

50/60ml：0.10ml/h-1200.00ml/h

Increment

0.01ml/h

Preset Time

1s～99hr59min59s

Parameter Changed during Injection

Support change of VTBI, flow rate during injection

Accuracy

≤±2%（±1% mechanical accuracy included）

Preset Volume(VTBI)

0.10-9999.99ml&empty

Accumulated Volume

0.00-9999.99ml

Purge Rate

5ml：30.00-60.00ml/h         10ml：150.00-300.00ml/h

20ml：200.00-400.00ml/h；    30ml：300.00-600.00ml/h

50ml：600.00-1200.00ml/h

Bolus Rate

5ml：0.10ml/h-60.00ml/h          10ml：0.10ml/h-300.00ml/h

20ml：0.10ml/h-400.00ml/h        30ml：0.10ml/h-600.00ml/h

50/60ml：0.10ml/h-1200.00ml/h

KVO

0.10 -5.00ml/h adjustable

Occlusion Pressure

8 level adjustable，20Kpa-150Kpa，dynamically pressure value display.

Alarm

Finished, near finished, near empty, empty, occlusion, syringe disconnected, no operation, parameter error, syringe error, low battery, battery lost, battery ran out, AC power lost, abnormal injection, communication error, finished! KVO.

Syringe Management

Preset 20 syringe brands, can add or edit the brand, accept different brands after calibration

Display

3.5’TFT color LCD, 10 level brightness adjustable

Pressure Release Function

Pressure release function after occlusion

Power Supply

AC Power：100V-240V，50/60Hz，≦45W

Battery

Rechargeable Lithium battery, DC11.1V，3000mAh；operating time: ≥9h @5ml/h

Alarm Voice

Standard Medical Alarm Voice with Mute function, 8 levels adjustable.

Event Log

10000 event log

Operation Environment

+5℃- +40℃，Relative humidity：20%-90%；Atmospheric pressure：70 – 106 Kpa

Classification

Class II， Type CF；IPX4

Dimension

Size：275mm×145 mm×160mm，Weight：2.1kg

Other Function

Double CPU, Password function, 90 ºratable IV pole, 4 soft function key: key lock function, numeric keypad, sleeping function

Application

Intravenous injection
