Syringe Pump- Double Channel
 Syringe Pump- Double Channel

Specification of Syringe Pump

Injection Mode

Constant rate, time/volume mode, drug weight mode, micro-mode, programmable mode, drug library mode

Syringe Size

5ml10ml20ml30ml50/60mlauto-recognition

Flow Rate

5ml0.10ml/h-60.00ml/h          10ml0.10ml/h-300.00ml/h

20ml0.10ml/h-400.00ml/h        30ml0.10ml/h-600.00ml/h

50/60ml0.10ml/h-1200.00ml/h

Increment

0.01ml/h

Preset Time

1s99hr59min59s

Parameter Changed during Injection

Support change of VTBI, flow rate during injection

Accuracy

≤±2%±1% mechanical accuracy included

Preset Volume(VTBI)

0.10-9999.99ml&empty

Accumulated Volume

0.00-9999.99ml

Purge Rate

5ml30.00-60.00ml/h         10ml150.00-300.00ml/h

20ml200.00-400.00ml/h    30ml300.00-600.00ml/h

50ml600.00-1200.00ml/h

Bolus Rate

5ml0.10ml/h-60.00ml/h          10ml0.10ml/h-300.00ml/h

20ml0.10ml/h-400.00ml/h        30ml0.10ml/h-600.00ml/h

50/60ml0.10ml/h-1200.00ml/h

KVO

0.10 -5.00ml/h adjustable

Occlusion Pressure

8 level adjustable20Kpa-150Kpadynamically pressure value display.

Alarm

Finished, near finished, near empty, empty, occlusion, syringe disconnected, no operation, parameter error, syringe error, low battery, battery lost, battery ran out, AC power lost, abnormal injection, communication error, finished! KVO.

Syringe Management

Preset 20 syringe brands, can add or edit the brand, accept different brands after calibration

Display

5.0’TFT color LCD, 10 level brightness adjustable

Pressure Release Function

Pressure release function after occlusion

Power Supply

AC Power100V-240V50/60Hz45W

Battery

Rechargeable Lithium battery, DC11.1V3000mAhoperating time: ≥6h @5ml/h

Alarm Voice

Standard Medical Alarm Voice with mute function, 8 levels adjustable.

Event Log

10000 event logs

Operation Environment

+5- +40Relative humidity20%-90%Atmospheric pressure70 – 106 Kpa

Classification

Class II Type CFIPX4

Dimension

Size290mm×150 mm×224mmWeight3.5kg

Other Function

Double CPU, Password function, 90 ºratable IV pole, 4 soft function key: key lock function, numeric keypad, sleeping function

Application

Intravenous injection
